# Envi-HUD

***

## Prerequisites

{% hint style="info" %}

* A working FiveM Server
* Basic understanding of FiveM server setup and resource management
* An up-to-date version of [ox\_lib](https://github.com/CommunityOx/ox_lib)
* Followed the [First Steps](https://envi-scripts-organization.gitbook.io/documentation/premium-scripts/first-steps-read-first) guide
* Envi-Bridge (added to your CFX Portal automatically when HUD is purchased)
  * <mark style="color:orange;">Requires version 0.3.9 or higher</mark>
* The packaged `web/build/` folder from your download
* Inventory items matching `Config.Items`
  {% endhint %}

***

## [Tebex](https://envi-scripts.tebex.io/package/6632728)

***

## Features

ENVI-HUD is a highly optimized next-gen HUD system for your FiveM Server. The script offers optimal performance while instantly updating real-time info for player status, vehicle stats, and server details etc - all packed into a modern interface with over 150+ customisation options!

<figure><img src="https://816912809-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FHaTfLRA7uCNOQ4cIXQD2%2Fuploads%2FhgJ2PhH8IeQrEtmBfuzc%2F2.png?alt=media&#x26;token=23c65f1d-cf13-466f-acfe-71c6b5d064bd" alt=""><figcaption></figcaption></figure>

<figure><img src="https://816912809-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FHaTfLRA7uCNOQ4cIXQD2%2Fuploads%2FLKgmvlr0TJa30heQo72O%2F3.png?alt=media&#x26;token=871fcfe4-7bde-489a-b9f1-406597f27857" alt=""><figcaption></figcaption></figure>

### Customization

<figure><img src="https://816912809-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FHaTfLRA7uCNOQ4cIXQD2%2Fuploads%2Fh5y60P4qfmQqtf5hrII5%2F4.png?alt=media&#x26;token=1c749f31-0992-48e8-87c2-e51ab797fe4d" alt=""><figcaption></figcaption></figure>

<figure><img src="https://816912809-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FHaTfLRA7uCNOQ4cIXQD2%2Fuploads%2Fe7bCdwWxMaVbBxbEe59c%2F5.png?alt=media&#x26;token=70719aa4-9e8e-4f0c-b852-25903e6806c6" alt=""><figcaption></figcaption></figure>

<figure><img src="https://816912809-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FHaTfLRA7uCNOQ4cIXQD2%2Fuploads%2FGtRN690mN1Zw4ySLGywA%2F6.png?alt=media&#x26;token=2b22681f-bb23-4364-b6bc-01c9054af21a" alt=""><figcaption></figcaption></figure>

### Player Status

* Health
* Armor
* Hunger
* Thirst
* Stress
* Stamina
* Voice Activity
* Voice Proximity

<figure><img src="https://816912809-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FHaTfLRA7uCNOQ4cIXQD2%2Fuploads%2FntGVCgikLwJH1Hf4Nif1%2F11.png?alt=media&#x26;token=aceebb87-839c-4b61-a0e8-221379816619" alt=""><figcaption></figcaption></figure>

### Extra Vehicle Features

* MANY Speedometer Choices
* Choose Between MPH or km/h
* Advanced Harness System
* Cruise Control with Speed Adjustment
* Persistent Handbrakes
* Turn indicators and Hazard controls
* Engine RPM display
* Handbrake status

### Extra Player Features

* Built-In Stress System for ALL Frameworks
* Extra Ragdoll Feature (crash into walls/ objects when you jump into them, lol)

### Advanced Harness System

The HUD includes a comprehensive vehicle harness system with:

* 3 Different Harness Levels
* Choice of Interaction Types
* Item-Based Installation by Mechanics
* Vehicle Persistence - (Harnesses will be applied to your vehicle forever)
* Configurable Protection Levels

### Reimagined Stress System

The HUD includes an all new stress management system that works with any framework and has many different triggers and extra features

<figure><img src="https://816912809-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FHaTfLRA7uCNOQ4cIXQD2%2Fuploads%2FQignr3QEKQHfOjjttdFx%2F9.png?alt=media&#x26;token=19501c79-f024-4789-850f-decbc9383c61" alt=""><figcaption></figcaption></figure>

#### Job-Based Stress Multipliers

* Customize stress impact based on player jobs
* Set different multipliers for different professions
* Completely disable stress for specific jobs
* Perfect for roleplay servers

```lua
JobStressMultiplier = {
    ['police'] = 0.5,    -- Police officers handle stress better.. (Half Stress)
    ['ambulance'] = 0.7, -- Medical professionals are trained for stress
    ['unemployed'] = 1.2, -- Higher stress impact
    ['developer'] = 0.0,   -- We get enough stress already... (No Stress Plz)
}
```

#### Stress Triggers

* High-speed driving with configurable thresholds
* Combat actions (shooting, getting shot, melee fights)
* Vehicle crashes
* Configurable update intervals

#### Speed-Based Stress

* Multiple speed ranges with different stress impacts
* Additional stress multiplier when driving without seatbelt
* Vehicle class exceptions (bikes, boats, aircraft, etc.)

### Install

1. Follow [FIRST STEPS (READ FIRST)](https://envi-scripts-organization.gitbook.io/documentation/premium-scripts/first-steps-read-first).
2. Start `envi-bridge` before `envi-hud`.
3. Keep the packaged `web/build/` folder inside the resource.
4. If you are not using a global target resource, follow the manifest note and set target options to match your setup.
5. On production, set `Config.Debug = false` and `Config.TestMode = false`.
6. Do not run another progress bar resource with the same provide.

### Critical live-server notes

The three highest-risk settings are:

* `Config.Debug`
* `Config.TestMode`
* `Config.InitializeDelay`

If any of those are wrong on production, the HUD can feel broken even when the rest of the install is fine.

### Safe edit points

The main supported edit areas are:

* `shared/config.lua`
* `client/client_open.lua`
* `client/progressbar.lua`
* `server/server_open.lua`

### Register these items

Default harness items:

* `harness`
* `advanced_harness`
* `ultra_harness`
* `mech_toolkit`

See the full snippets on [Inventory Setup](https://envi-scripts-organization.gitbook.io/documentation/premium-scripts/envi-hud/inventory-setup).

### First-time admin setup

The first admin to join can place HUD elements, choose a theme, and save the default layout for new players.

If nobody saves a layout, the HUD falls back to the built-in default. That fallback cannot be edited.

See [First Time Setup](https://envi-scripts-organization.gitbook.io/documentation/premium-scripts/envi-hud/first-time-setup) for the full flow.

### Helpful links

* [Critical Live-Server Flags](https://envi-scripts-organization.gitbook.io/documentation/premium-scripts/envi-hud/critical-live-server-flags)
* [Database and Settings](https://envi-scripts-organization.gitbook.io/documentation/premium-scripts/envi-hud/database-and-settings)
* [Common Issues](https://envi-scripts-organization.gitbook.io/documentation/premium-scripts/envi-hud/common-issues)
* [Inventory Setup](https://envi-scripts-organization.gitbook.io/documentation/premium-scripts/envi-hud/inventory-setup)
* [Open Lua Customization](https://envi-scripts-organization.gitbook.io/documentation/premium-scripts/envi-hud/open-lua-customization)
* [Progress Bar Integration](https://envi-scripts-organization.gitbook.io/documentation/premium-scripts/envi-hud/progress-bar-integration)
* [Seatbelt and Harness](https://envi-scripts-organization.gitbook.io/documentation/premium-scripts/envi-hud/seatbelt-and-harness)
* [HUD Settings and Theming](https://envi-scripts-organization.gitbook.io/documentation/premium-scripts/envi-hud/hud-settings-and-theming)
* [Exports and Events](https://envi-scripts-organization.gitbook.io/documentation/premium-scripts/envi-hud/exports-and-events)
* [Commands](https://envi-scripts-organization.gitbook.io/documentation/premium-scripts/envi-hud/commands)

***

## Preview

{% embed url="<https://www.youtube.com/watch?t=13s&v=AGy3hkzG9i0>" %}


---
